Description
- Precision Self Centering High Grip Machine Vices are compact, rigid & specially designed for Precision Milling, Grinding & CNC Operations.
- It has a Compact Design with large opening suitable for 4th & 5th Axis Rotary Tables.
- This Vice is suitable for holding two workpieces with an optional intermediate jaw.
- Made from Unbreakable High Strength Ductile Iron Body.
- It has Grounded Top & Bottom.
- High Quality Alloy Steel, Case Hardened HRC 60 ± 2 clamping jaws for high performance & longer life without wear.
- It comes with Tenon & tenon slots for effortless truing on the vice of the machine table.
- Accuracy in parallelism & squareness within 0.02 / 100 mm.
- Interchangeable Jaw Plates are also available.
- Smooth & effortless handle movement to achieve high clamping force. (Max: 3000 Kg.)
| Item Code No. | ABM-VC-11570 | ABM-VC-11571 |
|---|---|---|
| Size Inches | 6" | 6" |
| Width of Jaws mm | 150 | 150 |
| Opening of Jaws mm | 250 | 380 |
| Lenght of Jaws mm | 320 | 500 |
| Height Overall mm | 113 | 130 |
| Tenon Slot Size mm | 20 | 20 |
| Weight Approx Kg. | 20 Kg. | 40 Kg. |
