Description
• High Quality Alloy Steel.
• Conventional and CNC controlled milling machines-for efficient precision machining.
• Horizontal installation – great variability and flexibility.
• Excellent ease of operation guarantees optimal handling for every application.
• Fast adjustment for clamping range presetting.
• Accuracy in Squareness within 0.02/100MM.
• Fixing on the machine table by means of mounting holes in the vice base.
• Optional center jaw allows two or more workpieces to be clamped.
• Hardness 60 + HRC
| Item code No. | ABM-VC-11325 |
|---|---|
| Size in Inches | 6 Inch (150 mm) |
| Width of Jaws mm | 150 |
| Opening of Jaws mm | 255 |
| Depth of Jaws mm | 48 |
| Overall Length mm | 485 |
| Overall Height mm | 105 |
| Overall Width mm | 150 |
| Tenon Slot Size mm | 20 |
| Weight Approx Kg. | 27 |
