A rotary table is a precision work positioning device used in metalworking. It enables the operator to drill or cut work at exact intervals around a fixed (usually horizontal or vertical) axis. Some rotary tables allow the use of index plates for indexing operations, and some can also be fitted with dividing plates that enable regular work positioning at divisions for which indexing plates are not available.

Loading...

Description

• Can be tilted from 0 to 180 Degree.
• Table clamping surface are precision ground and cylindrical center bore concentric.
• Table Surface id accurately Ground and base of the body to ensure smooth Rotation.
• Engage & Disengage function for manual indexing.
• Center Sleeve is  MT2.
• Vertical Center Height  is  85 mm.



Item Code No.TypeTable Dia.Overall HeightT Slot Width
mm
Gear Ratio
ABM-VC-2580Tilting4" / 100mm2-1/2" / 66mm14mm72:1
ABM-VC-2581Rotary Table + Clamping Kit
ABM-VC-2582Rotary Table + Clamping Kit + Tailstock
