Description
• Rigid Material Vise Body of Ductile Iron.
• Clamping Force : 4000-4500 KGF.
• Sliding Bed ways hardened and ground.
• Hydraulic- Booster system for maximum clamping pressure with minimum force.
• Down thrust Semi – Sphere segment mechanism eliminates Jaw Lifting and Work Lift.
• Quick of clamping & locking and easy of operation.
• Accuracy in Squareness within 0.02/1OO MM.
• Hardened and Ground Guide Ways.
| Item code No. | ABM-VC-11320 | ABM-VC-11321 |
|---|---|---|
| Size in Inches | 6 Inch (150 mm) | 6 Inch (150 mm) |
| Width of Jaws mm | 160 | 160 |
| Opening of Jaws mm | 200 | 300 |
| Depth of Jaws mm | 58 | 58 |
| Overall Length mm | 520 | 710 |
| Overall Height mm | 165 | 165 |
| Overall Width mm | 160 | 160 |
| Tenon Slot Size mm | 20 | 20 |
| Weight Approx Kg. | 50 | 60 |
