Hand Taps – Carbon Steel & HSS
Esp
Roscas de macho
Fr
Tarauds
De
Handgewindebohrer
• Hand taps are used to create screw threads ,which is called threading .
• Taps can be used to either cut new threads or repair damaged threads.
• Internal threading is Done by using a tool called a TAP in a hole drilled to a specific diameter for the thread size and pitch you want to cut.
• Manufactured from Carbon Steel and HSS.
• Precisely Hardened and Tempered for long Life.
• All Taps are right hand.
• Left Hand Taps also available.
• Packed as set of 3 Pcs (Taper Tap , Second Tap and Bottoming Tap).
• Also available in BSF, UNF, UNC, BSP, BA, BSPT and NPT Threads.
• Machine Taps also available.
MM Size – Thread Angle 60º
| Carbon Steel Item code No. | HSS Item code No. | Size mm | Thread Per Pitch |
|---|---|---|---|
| ABM-CT-12540 | ABM-CT-12590 | 2.0 | 0.40 |
| ABM-CT-12541 | ABM-CT-12591 | 2.5 | 0.45 |
| ABM-CT-12542 | ABM-CT-12592 | 2.6 | 0.45 |
| ABM-CT-12543 | ABM-CT-12593 | 3.0 | 0.50 |
| ABM-CT-12544 | ABM-CT-12594 | 3.5 | 0.60 |
| ABM-CT-12545 | ABM-CT-12595 | 4.0 | 0.70 |
| ABM-CT-12546 | ABM-CT-12596 | 4.5 | 0.75 |
| ABM-CT-12547 | ABM-CT-12597 | 5.0 | 0.80 |
| ABM-CT-12548 | ABM-CT-12598 | 5.5 | 0.90 |
| ABM-CT-12549 | ABM-CT-12599 | 6.0 | 1.00 |
| ABM-CT-12550 | ABM-CT-12600 | 7.0 | 1.00 |
| ABM-CT-12551 | ABM-CT-12601 | 8.0 | 1.00 / 1.25 / 1.50 |
| ABM-CT-12552 | ABM-CT-12602 | 9.0 | 1.25 / 1.50 |
| ABM-CT-12553 | ABM-CT-12603 | 10.0 | 1.00 / 1.25 / 1.50 |
| ABM-CT-12554 | ABM-CT-12604 | 11.0 | 1.00/ 1.25 / 1.50 |
| ABM-CT-12555 | ABM-CT-12605 | 12.0 | 1.00 / 1.25 / 1.50 / 1.75 |
| ABM-CT-12556 | ABM-CT-12606 | 13.0 | 1.50 / 1.75 |
| ABM-CT-12557 | ABM-CT-12607 | 14.0 | 1.00 / 1.25 / 1.50 / 2.00 |
| ABM-CT-12558 | ABM-CT-12608 | 15.0 | 1.50 / 2.00 |
| ABM-CT-12559 | ABM-CT-12609 | 16.0 | 1.25 / 1.50 / 2.00 |
| ABM-CT-12560 | ABM-CT-12610 | 18.0 | 1.50 / 2.50 |
| ABM-CT-12561 | ABM-CT-12611 | 20.0 | 1.50 / 2.00 / 2.50 |
| ABM-CT-12562 | ABM-CT-12612 | 22.0 | 1.50 / 2.00 / 2.50 |
| ABM-CT-12563 | ABM-CT-12613 | 24.0 | 1.50 / 2.00 / 3.00 |
| ABM-CT-12564 | ABM-CT-12614 | 27.0 | 1.50 / 2.00 / 3.00 |
| ABM-CT-12565 | ABM-CT-12615 | 30.0 | 1.50 / 2.00 / 3.00 / 3.50 |
| ABM-CT-12566 | ABM-CT-12616 | 33.0 | 1.50 / 2.00 / 3.50 |
| ABM-CT-12567 | ABM-CT-12617 | 36.0 | 1.50 / 2.00 / 4.00 |
| ABM-CT-12568 | ABM-CT-12618 | 39.0 | 1.50 / 2.00 / 4.00 |
| ABM-CT-12569 | ABM-CT-12619 | 41.0 | 4.50 |
| ABM-CT-12570 | ABM-CT-12620 | 45.0 | 4.50 |
| ABM-CT-12571 | ABM-CT-12621 | 48.0 | 5.00 |
| ABM-CT-12572 | ABM-CT-12622 | 52.0 | 5.00 |
| ABM-CT-12573 | ABM-CT-12623 | 56.0 | 5.50 |
| ABM-CT-12574 | ABM-CT-12624 | 60.0 | 5.50 |
| Also available in BSF, UNF, UNC, BSP, BA, BSPT and NPT Threads While placing order please mention Carbon Steel or HSS | |||
INCHES Size – Thread Angle 55º – BSW
| Carbon Steel Item code No. | HSS Item code No. | Size Inches | Thread Per Pitch – BSW |
|---|---|---|---|
| ABM-CT-12640 | ABM-CT-12690 | 1/16” | 60 |
| ABM-CT-12641 | ABM-CT-12691 | 3/32” | 48 |
| ABM-CT-12642 | ABM-CT-12692 | 1/8” | 40 |
| ABM-CT-12643 | ABM-CT-12693 | 5/32” | 32 |
| ABM-CT-12644 | ABM-CT-12694 | 3/16” | 24 |
| ABM-CT-12645 | ABM-CT-12695 | 7/32” | 24 |
| ABM-CT-12646 | ABM-CT-12696 | 1/4” | 20 |
| ABM-CT-12647 | ABM-CT-12697 | 9/32” | 20 |
| ABM-CT-12648 | ABM-CT-12698 | 5/16” | 18 |
| ABM-CT-12649 | ABM-CT-12699 | 3/8” | 16 |
| ABM-CT-12650 | ABM-CT-12700 | 7/16” | 14 |
| ABM-CT-12651 | ABM-CT-12701 | 1/2” | 12 |
| ABM-CT-12652 | ABM-CT-12702 | 9/16” | 12 |
| ABM-CT-12653 | ABM-CT-12703 | 5/8” | 11 |
| ABM-CT-12654 | ABM-CT-12704 | 11/16” | 11 |
| ABM-CT-12655 | ABM-CT-12705 | 3/4” | 10 |
| ABM-CT-12656 | ABM-CT-12706 | 13/16” | 10 |
| ABM-CT-12657 | ABM-CT-12707 | 7/8” | 9 |
| ABM-CT-12658 | ABM-CT-12708 | 15/16” | 9 |
| ABM-CT-12659 | ABM-CT-12709 | 1” | 8 |
| ABM-CT-12660 | ABM-CT-12710 | 1-1/8” | 7 |
| ABM-CT-12661 | ABM-CT-12711 | 1-1/4” | 7 |
| ABM-CT-12662 | ABM-CT-12712 | 1-3/8” | 6 |
| ABM-CT-12663 | ABM-CT-12713 | 1-1/2” | 6 |
| ABM-CT-12664 | ABM-CT-12714 | 1-5/8” | 5 |
| ABM-CT-12665 | ABM-CT-12715 | 1-3/4” | 5 |
| ABM-CT-12666 | ABM-CT-12716 | 1-7/8” | 4-1/2 |
| ABM-CT-12667 | ABM-CT-12717 | 2” | 4-1/2 |
| ABM-CT-12668 | ABM-CT-12718 | 2-1/4” | 4 |
| ABM-CT-12669 | ABM-CT-12719 | 2-1/2” | 4 |
| ABM-CT-12670 | ABM-CT-12720 | 2-3/4” | 3-1/2 |
| ABM-CT-12671 | ABM-CT-12721 | 3” | 3-1/2 |
| ABM-CT-12672 | ABM-CT-12722 | 3-1/4” | 3-1/4 |
| ABM-CT-12673 | ABM-CT-12723 | 3-1/2” | 3-1/4 |
| ABM-CT-12674 | ABM-CT-12724 | 3-3/4” | 3 |
| ABM-CT-12675 | ABM-CT-12725 | 4” | 3 |
| Also available in BSF, UNF, UNC, BSP, BA, BSPT and NPT Threads While placing order please mention Carbon Steel or HSS | |||
