Description
Dimension in mm
| Item Code No. | Type | D | D | L | L1 | G | G1 |
|---|---|---|---|---|---|---|---|
| ABM-IMT-7430 | SK 30 / SMS 16 x 030 | 16 | 32 | 30 | 14 | M 12 | M 8 |
| ABM-IMT-7431 | SK 30 / SMS 16 x 030 | 22 | 40 | 30 | 16 | M 12 | M 10 |
| ABM-IMT-7432 | SK 40 / SMS 16 x 060 | 16 | 32 | 60 | 14 | M 16 | M 8 |
| ABM-IMT-7433 | SK 40 / SMS 16 x 120 | 16 | 32 | 120 | 14 | M 16 | M 8 |
| ABM-IMT-7434 | SK 40 / SMS 16 x 060 | 22 | 40 | 60 | 16 | M 16 | M 10 |
| ABM-IMT-7435 | SK 40 / SMS 16 x 120 | 22 | 40 | 120 | 16 | M 16 | M 10 |
| ABM-IMT-7436 | SK 40 / SMS 27 x 045 | 27 | 48 | 45 | 18 | M 16 | M 12 |
| ABM-IMT-7437 | SK 40 / SMS 27 x 105 | 27 | 48 | 105 | 18 | M 16 | M 12 |
| ABM-IMT-7438 | SK 40 / SMS 32 x 045 | 32 | 58 | 45 | 20 | M 16 | M 16 |
| ABM-IMT-7439 | SK 40 / SMS 32 x 075 | 32 | 58 | 75 | 20 | M 16 | M 16 |
| ABM-IMT-7440 | SK 40 / SMS 16 x 075 | 16 | 32 | 75 | 14 | M 24 | M 8 |
| ABM-IMT-7441 | SK 40 / SMS 16 x 120 | 16 | 32 | 120 | 14 | M 24 | M 8 |
| ABM-IMT-7442 | SK 50 / SMS 22 x 075 | 22 | 40 | 75 | 16 | M 24 | M 10 |
| ABM-IMT-7443 | SK 50 / SMS 22 x 075 | 22 | 40 | 120 | 16 | M 24 | M 10 |
| ABM-IMT-7444 | SK 50 / SMS 27 x 075 | 27 | 48 | 60 | 18 | M 24 | M 12 |
| ABM-IMT-7445 | SK 50 / SMS 27 x 075 | 27 | 48 | 105 | 18 | M 24 | M 12 |
| ABM-IMT-7446 | SK 50 / SMS 32 x 075 | 32 | 58 | 45 | 20 | M 24 | M 16 |
| ABM-IMT-7447 | SK 50 / SMS 32 x 075 | 32 | 58 | 75 | 20 | M 24 | M 16 |
| ABM-IMT-7448 | SK 50 / SMS 40 x 045 | 40 | 70 | 45 | 23 | M 24 | M 20 |
| ABM-IMT-7449 | SK 50 / SMS 40 x 075 | 40 | 70 | 75 | 23 | M 24 | M 20 |
| ABM-IMT-7450 | SK 50 / SMS 50 x 060 | 50 | 90 | 60 | 26 | M 24 | M 24 |
