Description
• Useful for efficient holding of endmills, slot drills or similar tooling in light and heavy duty milling machines and small lathes.
• Precisely ground externally and internally to very close tolerances with concentricity within + .10 Microns.
• Eliminates the need of a collet chuck.
• The machining area is easily visible while doing intricate components.
• Manufactured from case Hardened Steel.
| Item Code No. | Shank Taper | Holding Dia. Inch | Holding Dia. mm | Draw Bar Threads |
|---|---|---|---|---|
| ABM-IMT-4070 | R8 | 3/16 | 5 | 7/16 UNF |
| ABM-IMT-4071 | R8 | 1/4 | 6 | 7/16 UNF |
| ABM-IMT-4072 | R8 | 3/8 | 10 | 7/16 UNF |
| ABM-IMT-4073 | R8 | 1/2 | 12 | 7/16 UNF |
| ABM-IMT-4074 | R8 | 5/8 | 16 | 7/16 UNF |
| ABM-IMT-4075 | MT2 | 3/16 | 5 | 3/8 BSW |
| ABM-IMT-4076 | MT2 | 1/4 | 6 | 3/8 BSW |
| ABM-IMT-4077 | MT2 | 3/8 | 10 | 3/8 BSW |
| ABM-IMT-4078 | MT2 | 1/2 | 12 | 3/8 BSW |
| ABM-IMT-4079 | MT3 | 3/16 | 5 | 3/8 BSW |
| ABM-IMT-4080 | MT3 | 1/4 | 6 | 3/8 BSW |
| ABM-IMT-4081 | MT3 | 3/8 | 10 | 3/8 BSW |
| ABM-IMT-4082 | MT3 | 1/2 | 12 | 3/8 BSW |
