Double Ended Boring Bar

Boring Bars With Holders
double ended boring bars with holderdouble ended boring barsDouble ended boring bar holder

Print

These robust Boring Bars are perfect for most deep boring chores on your lathe. They are double-ended and hold square bits at 90deg or at 45deg. Comes with a wrench and tool bit Square holder. It is suitable for general purpose applications and can be used on iron, steel, aluminum, brass, copper and wood. Boring bars are used to enlarge or finish the inside diameter of a work piece.

Compare

Product Description

• Double Ended one piece boring bars have 90° & 45° square ends.
• Set Supplied with Boring Bar, Holder, Allen Key and Screw.
• Tool Bits also available on extra cost.
• Shiny black finish.
• Available with and without Holders.
• Only Holder and only Boring Bar also available separately.
• Single Ended Boring Bars also available.



Item Code No.
Complete Set
Bar Size
Dia.
Bar Size
Length
Holder Size
Length
Holder Size
Square
Square Bit
Size
ABM-IMT-61003/8”4-1/2”2-1/8”1/2”1/8”
ABM-IMT-61017/16”5-1/4”2-1/2”5/8”3/16”
ABM-IMT-61029/16”6-3/4”3”3/4”1/4”
ABM-IMT-61033/4”9”3-3/4”1”5/16”
ABM-IMT-61047/8”11-1/2”4-1/2”1-1/8”3/8”
ABM-IMT-61051-1/8”14”5”1-3/8”7/16”
ABM-IMT-61061-1/4”15”5-1/4”1-5/8”1/2”
ABM-IMT-61071-3/8”16”6”1-3/4”5/8”
ABM-IMT-61081-1/2”18”6”2”3/4”
ABM-IMT-61092”20”7”3”1”
