Center Punch – Round & Square Head / Centre Punch
Esp
Granetes de trazar
Fr
Pointeau
De
Körner
• Knurling on the shank provide a positive finger grip.
• Square head provides larger area for striking & prevents the punch from rolling off.
• Square head Center Punch comes with round Shank and Square Striking End.•
• Made from Tool Steel.
• Hardened and ground.
• Black shiny finish / Black oxide Finish with knurled body for easy grip.
• Available in plastic pouch in individual sizes and also in a set of 5 pcs.
Square Head
| Item Code No. Square Head | Tip Dia. Inch | Tip Dia. mm | Overall Length | Square Size |
|---|---|---|---|---|
| ABM-PN-9740 | 1/16 | 1.5 | 4″ / 100 mm | 3/8″ / 9.5 mm |
| ABM-PN-9741 | 5/64 | 2.0 | 4″ / 100 mm | 3/8″ / 9.5 mm |
| ABM-PN-9742 | 3/32 | 2.5 | 4″ / 100 mm | 3/8″ / 9.5 mm |
| ABM-PN-9743 | 9/64 | 3.5 | 4″ / 100 mm | 3/8″ / 9.5 mm |
| ABM-PN-9744 | 5/32 | 4.0 | 4″ / 100 mm | 3/8″ / 9.5 mm |
| ABM-PN-9745 | 1/8 | 3.2 | 4″ / 100 mm | 3/8″ / 9.5 mm |
| ABM-PN-9746 | 3/16 | 4.8 | 4-1/2″ / 115 mm | 7/16″ / 11.0 mm |
| ABM-PN-9747 | 1/4 | 6.3 | 5″ / 125 mm | 9/16″ / 14.0 mm |
| ABM-PN-9748 | Set of 5 Centre Punches in a pouch consisting of 1/16, 5/64, 3/32, 9/64, 5/32 |
|||
Round Head
| Item Code No. Round Head | Tip Dia. Inch | Tip Dia. mm | Overall Length |
|---|---|---|---|
| ABM-PN-9749 | 1/16 | 1.5 | 3″ / 75 mm |
| ABM-PN-9750 | 5/64 | 2.0 | 4″ / 100 mm |
| ABM-PN-9751 | 3/32 | 2.5 | 4″ / 100 mm |
| ABM-PN-9752 | 9/64 | 3.5 | 4″ / 100 mm |
| ABM-PN-9753 | 5/32 | 4.0 | 4″ / 100 mm |
| ABM-PN-9754 | 5/16 | 8.0 | 4″ / 100 mm |
| ABM-PN-9755 | 1/8 | 3.2 | 4″ / 100 mm |
| ABM-PN-9756 | 11/64 | 4.4 | 4″ / 100 mm |
| ABM-PN-9757 | 3/16 | 4.8 | 4-1/2″ / 115 mm |
| ABM-PN-9758 | 1/4 | 6.3 | 5″ / 125 mm |
| ABM-PN-9759 | 3/8 | 9.5 | 6″ / 150 mm |
| ABM-PN-9760 | Set of 5 Centre Punches in a pouch consisting of 1/16, 5/64, 3/32, 9/64, 5/32 |
||
